FD376AG
Felimann always follows the advanced engine technology, designed the exquisite fuel injection system, exquisite technology and strict quality concept, so that the Felimann engine output capacity is strong, safe and reliable.
Get A Quote

Product Details

  • Good parts versatility

  • Economical,reliable and durable

  • Excellent fuel system

  • Lower exhaust emissions

  • Integral cylinder

  • Adjustable coolant temperature

  • Mixed lubrication

  • Wide range of applications

ModelFD376AG
Type3-cylinder,4-stroke,Water-cooled,inline,Electirc start
Bore x Stroke76×77 mm
Displacement1.048 L
Compression Ratio21.5:1
Rated Power15.3/3000 kW/rpm
Rated Speed17.5/3600 kW/rpm
Max Torque/Speed52/2200 N.m/rpm
Min.Adjustable Idle Speed≤1000 rpm
Lubrication SystemPressure Splash
Rotating (Face PTO)Anticlockwise
Fuel Type0#(Summer),-10#( Winter),-35#(Chill Cold)Diesel
Fuel Consumption280/3000,295/3600 g/kWh
Lube4.8L SAE10W-30、15W-40(CD grade or above)
Coolant Capacity (Engine)2L
Coolant Capacity (Radiator)4L
Start Motor12V 1.4KW
DC Alternator14V 20A
Battery Capacity12V 65Ah
Dimension(LxWxH)558x481x587 mm
Net Weight110 kg
